SN74LVC244ADWR IC Integrated Circuit Chip Buffer Line Driver Logic ICs

Product Categories
SZ ADE Electronics Co., Ltd
Contact Now

SN74LVC244ADWR IC Integrated Circuit Chip Buffer Line Driver Logic ICs

Brand Name : Original

Model Number : SN74LVC244ADWR

Certification : Original

Place of Origin : Original

MOQ : 1

Price : USD

Payment Terms : T/T

Delivery Time : 5-7working days

Packaging Details : carton box

Input Signal Type : Single-Ended

Pd - Power Dissipation : 500mW (1/2 W)

Logic Type : CMOS

Supply Current - Max : 1 UA

Output Type : 3-State

Product : SN74LVC244ADWR

Contact Now

SN74LVC244ADWR IC Buffers Line Drivers Logic ICs original 20-SOIC 3-State

Features of SN74LVC244ADWR

• Operates From 1.65 V to 3.6 V
• Inputs Accept Voltages to 5.5 V
• Specified From –40°C to +85°C and
–40°C to +125°C
• Maximum tpd of 5.9 ns at 3.3 V
• Typical VOLP (Output Ground Bounce)
< 0.8 V at VCC = 3.3 V, TA = 25°C
• Typical VOHV (Output VOH Undershoot)
> 2 V at VCC = 3.3 V, TA = 25°C
• Supports Mixed-Mode Signal Operation on
All Ports (5-V Input or Output Voltage With
3.3-V VCC)
• Ioff Supports Live Insertion, Partial-Power-Down
Mode, and Back-Drive Protection
• Can Be Used as a Down Translator to Translate Inputs From a Maximum of 5.5 V Down to the VCC Level
• Available in Ultra Small Logic QFN Package (0.5mm Maximum Height)
• Latch-Up Performance Exceeds 250 mA PerJESD 17
• ESD Protection Exceeds JESD 22
– 2000-V Human-Body Model
– 1000-V Charged-Device Model
Product
SN74LVC244ADWR
Logic Type
Buffer, Non-Inverting
Number of Elements
2
Number of Bits per Element
4
Input Type
-
Output Type
3-State
Current - Output High, Low
24mA, 24mA
Voltage - Supply
1.65V ~ 3.6V
Operating Temperature
-40°C ~ 125°C (TA)
Mounting Type
Surface Mount
Package / Case
20-SOIC (0.295", 7.50mm Width)
Supplier Device Package
20-SOIC
Base Product Number
74LVC244

Environmental & Export Classifications
ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001

SN74LVC244ADWR IC Integrated Circuit Chip Buffer Line Driver Logic ICs
