ISO7641FMDWR Digital Isolator 4243Vrms 4 Channel 150Mbps 25kV/µs CMTI 16-SOIC

Product Categories
SZ ADE Electronics Co., Ltd
Contact Now

ISO7641FMDWR Digital Isolator 4243Vrms 4 Channel 150Mbps 25kV/µs CMTI 16-SOIC

Brand Name : original

Model Number : ISO7641FMDWR

Certification : original

Place of Origin : original

MOQ : 1

Price : negotiation

Payment Terms : T/T

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Number of Channels : 4

Inputs - Side 1/Side 2 : 3/1

Channel Type : Unidirectional

Voltage - Isolation : 4243Vrms

Common Mode Transient Immunity (Min) : 25kV/µs

Data Rate : 150Mbps

Propagation Delay tpLH / tpHL (Max) : 10.5ns, 10.5ns

Pulse Width Distortion (Max) : 2ns

Contact Now

ISO7641FMDWR Digital Isolator 4243Vrms 4 Channel 150Mbps 25kV/µs CMTI 16-SOIC

General Purpose Digital Isolator 4243Vrms 4 Channel 150Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)

Specifications of ISO7641FMDWR

TYPE DESCRIPTION
Category Isolators
Digital Isolators
Mfr Texas Instruments
Series -
Package Tape & Reel (TR)
Cut Tape (CT)
Product Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 3/1
Channel Type Unidirectional
Voltage - Isolation 4243Vrms
Common Mode Transient Immunity (Min) 25kV/µs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 10.5ns, 10.5ns
Pulse Width Distortion (Max) 2ns
Rise / Fall Time (Typ) 1.6ns, 1ns
Voltage - Supply 2.7V ~ 5.5V
Operating Temperature -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package 16-SOIC
Base Product Number ISO7641


Features of ISO7641FMDWR

• Signaling Rate: 150 Mbps
• Low Power Consumption, Typical ICC per Channel (3.3-V Supplies):
– ISO7640FM: 2 mA at 25 Mbps
– ISO7641FM: 2.4 mA at 25 Mbps
• Low Propagation Delay: 7-ns Typical
• Output Defaults to Low-State in Fail-Safe Mode
• Wide Temperature Range: –40°C to 125°C
• 50-KV/µs Transient Immunity, Typical
• Long Life With SiO2 Isolation Barrier
• Operates From 2.7-V, 3.3-V, and 5-V Supply Logic Levels
• Wide Body SOIC-16 Package
• Safety and Regulatory Approvals
– 6000 VPK / 4243 VRMS for 1 Minute per UL 1577
– VDE 6000 VPK Transient Overvoltage, 1414 VPK Working Voltage per DIN V VDE V 0884-10 (VDE V 0884-10):2006-12
– CSA Component Acceptance Notice 5A, IEC Device Information(1) 60950-1, IEC 61010-1, and IEC 60601-1 End Equipment Standards
– TUV 5 KVRMS Reinforced Insulation per SOIC (16) 10.30 mm × 7.50 mm EN/UL/CSA 61010-1
– CQC Reinforced Insulation per GB4943.1-2011


Applications of ISO7641FMDWR

• Optocoupler Replacement in:
– Industrial Fieldbus
– Profibus
– Modbus
– DeviceNet™ Data Buses
– Servo Control Interface
– Motor Control
– Power Supplies
– Battery Packs

Environmental & Export Classifications of ISO7641FMDWR

ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
